The FDV200S Direct Vent model provides sealed combustion which means that it draws outside air for combustion. This model are often vented either vertically or horizontally providing you with the ability to control where the unit is placed for the most efficient heat possible. Its Millivolt or IPI valve system allows operation during a power failure with Hi-Low heat and flame adjustment options so you'll be able to enjoy the view of your customizations. This unit also can be customized for convenience with options like remotes and digital thermostats.
Kingsman Direct Vent gas stove can be vented through the wall or up through your roof. This gas stove comes with a factory-installed fan, thermostatically controlled wireless remote control. you'll be able to use the remote to manage the speed of the fan and adjust the flame height. Also comes with a baby protection screen. Available in Natural gas or Liquid Propane.
Kingsman knows how to blow away the competition. That's why they created the Kingsman FDV200S Free Standing gas stove IPI Pilot. This dual burner system stove is a great addition to any living space, and therefore the added blower will help to keep you warm all winter long.
What's Included
- FDV200S Gas Stove on Legs
- Dual Burner
- Safety Screen
- Ceramic Glass
- Glowing Embers
Not Included (Sold Separately)
- Logs (Required)
- Fan Kit
- Refractory Liner
- Gas Conversion Kit
- Thermostats and Remote Controls
- Horizontal / Vertical Vent Starter Kit
- Venting Components
Features
- Safety screen barrier
- Mobile home approved
- Freestanding stove on legs
- Heat radiating ceramic glass
- Your choice of propane or natural gas
- Can be vented horizontally or vertically
- Fiber Oak Log Set with glowing embers
- Dual burner system, with Realistic Flame Pattern
- Approved for installation in a bedroom or bed sitting room
- Millivolt or IPI valve system allows operation during a power failure with Hi-Low heat and flame adjustment
Specifications
| Model | FDV200SLP |
| Fuel | Propane Gas |
| Gas Control | Millivolt |
| Input Max. | 26,000 BTU |
| Input Min. | 20,000 BTU |
| FE (P.4.1-15) | 67.47% / 69.89% |
| Glass Type | Ceramic |
| Certification | Heater |
| Bedroom Approved |
Yes |
| Orifice Size (0-4500ft) | 1/16" |
| Air Shutter | Fully Open |
| Gas Inlet Size | S.I.T. 820 Nova, 3/8” NPT |
| Gas Supply Pressure |
| Minimum | 11" |
| Normal | 11" |
| Maximum | 12" |
| Manifold Pressure High | 10 IN. W.C./2.61 KPa |
| Manifold Pressure Low | 6.3 IN. W.C./1.57 KPa |
Dimensions
| Width | 23" |
| Height | 31" |
| Depth | 19" |
| Viewing Area | 23" W x 18"H |
Warranty
- This Limited Lifetime Warranty applies only while the unit remains at the site of the original installation and only if the unit is installed inside the continental United States, Alaska, Hawaii, and Canada.
- The warranty applies only if the unit is installed and operated in accordance with the printed instructions and in compliance with applicable installation and building codes and good trade practices.
