The Empire Rushmore Clean Face 35 Inch Propane Gas Direct Vent Fireplace Insert is a direct vent gas insert designed to convert an existing wood burning fireplace into a propane fired heating appliance. The DVCT35CBN95 model uses a sealed combustion system with direct venting, drawing combustion air from outside and exhausting combustion byproducts outdoors. This design separates combustion from room air while allowing room air to circulate around the combustion chamber for heating.
The Rushmore Clean Face insert incorporates the TruFlame system, combining flame presentation with a glowing ember bed intended to resemble a natural wood fire. Its multifunction remote provides several operating options, including thermostat operation, Smart Thermostat operation that modulates flame height as the room approaches the selected temperature, and manual control. The remote also operates the included accent light and variable speed blower. With a maximum input of 35,000 BTU and a minimum input of 28,500 BTU when both burners operate, this propane direct vent insert provides zone heating for an existing fireplace opening.
Features
- TruFlame system provides realistic flame presentation with a glowing ember bed
- Multifunction remote supports thermostat, Smart Thermostat, and manual operation
- Remote controls variable flame height, accent lighting, and variable speed blower
- Direct vent sealed combustion system draws combustion air from outdoors and exhausts combustion byproducts outside
- Includes blower, accent light, ceramic glass, fine mesh barrier screen, and multifunction remote control
- Designed as an insert for converting an existing wood burning fireplace to a gas fired heat source
Specifications
| Specification | Details |
|---|---|
| Brand | Empire |
| Product | Rushmore Clean Face Direct Vent Insert |
| Model | DVCT35CBN95 |
| SKU | DVCT35CBN95P |
| Installation Type | Insert |
| Gas Type | Propane |
| Vent Type | Direct Vent |
| Venting | 3 x 4 Flex |
| Maximum BTU with Both Burners | 35,000 |
| Minimum BTU with Both Burners | 28,500 |
| Minimum BTU with Front Burner Only | 11,000 |
| KWH Maximum | 10.2 |
| KWH Minimum | 3.2 |
| Width | 35" |
| Height | 24" |
| Depth | 19" |
| Ceramic Glass Width | 29" |
| Ceramic Glass Height | 20" |
| Front Orifice | #57 |
| Rear Orifice | 1.40 mm |
| Front Air Shutter Opening | Fully Open |
| Rear Air Shutter Opening | Fully Open |
| Gas Inlet Shutoff Valve Pipe | 3/8" MIF |
| Maximum Gas Supply Pressure | 14 Inches Water Column |
| Minimum Gas Supply Pressure | 10.8 Inches Water Column |
| Manifold Pressure | 10 Inches Water Column |
| Weight | Not provided |
| Material | Not provided |
| Included | Fireplace insert, blower, accent light, ceramic glass, fine mesh barrier screen, multifunction remote control |
| Required and Sold Separately | Logs, liner, surround |
| Other Optional Components | Forged iron fronts and insets, beveled frames, surrounds and shroud, gas conversion kit |
| Combustion Chamber Warranty | 10 year limited warranty |
| Glass Warranty | Limited lifetime |
| Remote Control Warranty | 1 year limited warranty |
| Other Parts Warranty | 3 year limited warranty |
Technical Documents & Manuals
Product FAQs
1. What type of gas does the Empire Rushmore Clean Face 35 use?
The DVCT35CBN95 model is configured for propane gas. Its listed gas supply pressure range is 10.8 to 14 inches water column, with a manifold pressure of 10 inches water column.
2. What does the multifunction remote control operate?
The included multifunction remote can provide conventional thermostat operation, Smart Thermostat operation, or manual control. It also operates the variable flame height, accent light, and variable speed blower.
3. What is included with the Rushmore Clean Face Direct Vent Insert?
The insert includes the blower, accent light, ceramic glass, fine mesh barrier screen, and multifunction remote control. Logs, liner, and surround are required and sold separately.
