True North TN20 Wood Stove is a catalytic-free heating appliance designed for homeowners seeking an efficient wood-burning solution with straightforward operation. Built from standard 10-gauge steel, this model features metallic black legs, a heavy plate-steel top, and a gasketed cast iron door for durable everyday use. The clean glass air wash system helps keep the ceramic viewing glass clearer during operation, reducing the need for frequent cleaning while maintaining visibility of the fire.
Designed with EPA 2020 certification, the True North TN20 Wood Stove 31010009 delivers up to 60,000 BTU heat output (cord wood) with an EPA-rated output range of 13,900 to 29,200 BTU. Its 2.0 cu. ft. firebox accepts logs up to 18 inches, allowing longer burn cycles between refueling. A single-lever air control simplifies combustion management, while compatibility with both inside and outside combustion air provides installation flexibility where applicable. Mobile home approval further expands installation options, making this stove a practical choice for a variety of residential heating applications.
Features
- Catalytic-free combustion technology for reliable operation
- EPA 2020 Certified
- Air wash system helps keep the ceramic glass cleaner
- Heavy 10-gauge steel construction with heavy plate-steel top
- Gasketed cast iron door for durable performance
- Single-lever air control for straightforward operation
- Compatible with inside and outside combustion air
- Mobile home approved
- Metallic black leg design
Specifications
| Specification | Details |
|---|---|
| Brand | True North |
| Product Name | TN20 Wood Stove With Legs |
| SKU | 31010009 |
| Heat Output (Cord Wood) | 60,000 BTU |
| Heat Output (EPA) | 13,900–29,200 BTU |
| Efficiency (HHV) | 72.7% |
| Emissions | 1.6 g/hr |
| Firebox Size | 2.0 cu. ft. |
| Maximum Log Length | 18 in. |
| Construction Material | Standard 10-gauge steel |
| Door Material | Cast iron |
| Glass | Ceramic glass with air wash system |
| Air Control | Single-lever air control |
| Combustion System | Catalytic-free |
| Combustion Air | Inside and outside combustion air capable |
| Certification | EPA 2020 Certified |
| Mobile Home Approved | Yes |
| Finish | Metallic Black Legs |
Technical Documents & Manuals
Product FAQs
1. What is the heating output of the True North TN20 Wood Stove 31010009?
The True North TN20 Wood Stove provides up to 60,000 BTU heat output when using cord wood. Its EPA-rated heat output ranges from 13,900 to 29,200 BTU.
2. What size firewood can the TN20 Wood Stove accommodate?
The stove features a 2.0 cubic foot firebox and accepts logs up to 18 inches in length.
3. Does the True North TN20 Wood Stove use catalytic technology?
No. The True North TN20 Wood Stove uses catalytic-free combustion technology and is EPA 2020 Certified. It also includes an air wash system for the ceramic glass, a single-lever air control, and is compatible with inside and outside combustion air.
