The Empire Spirit Propane Gas Stove is a freestanding direct vent heating appliance designed to deliver dependable warmth with millivolt ignition and reliable operation. The Empire Spirit 27" Propane Gas Stove features a sealed combustion system that draws combustion air from outdoors while venting exhaust outside, helping maintain indoor air quality. Its millivolt control uses a standing pilot with a push-button piezo ignitor and can be operated with the built-in on/off switch or an optional remote control system.
This model includes Empire's Slope Glaze Burner with an expanded ember bed that creates naturally swirling flames for a realistic fire appearance. A hand-painted ceramic fiber log set and glowing embers further enhance the visual effect without changing the convenience of gas heating. With a heating input of 26,500 BTU/hr maximum and 21,000 BTU/hr minimum, it provides consistent heat output for everyday use. The direct vent design separates room air from combustion air and can continue providing heat during many winter power outages because the millivolt system does not rely on household electricity for basic operation. The package includes the medium steel stove, 4-piece log set, barrier screen, and Slope Glaze Burner.
Features
- Direct vent system draws combustion air from outdoors and exhausts gases outside.
- Millivolt ignition with standing pilot and push-button piezo ignitor.
- Operates using the concealed on/off switch or compatible optional remote controls.
- Slope Glaze Burner with expanded ember bed creates realistic swirling flames.
- Hand-painted ceramic fiber 4-piece log set enhances the authentic wood fire appearance.
- Freestanding medium steel stove designed for propane gas installation.
Specifications
| Specification | Details |
|---|---|
| Brand | Empire Hearth |
| Series | Spirit |
| Model | DVP30MS |
| SKU | DVP30MS30FP |
| Product Type | Freestanding Direct Vent Gas Stove |
| Fuel Type | Propane Gas |
| Vent Type | Direct Vent |
| Ignition | Millivolt Control |
| Maximum Input | 26,500 BTU/hr |
| Minimum Input | 21,000 BTU/hr |
| Vent Size | 4 x 6 5/8 in. |
| Gas Inlet | 3/8 in. |
| Orifice | 1.55 mm |
| Air Shutter | Full Open |
| Maximum Gas Supply Pressure | 13.0 in. W.C. (3.237 kPa) |
| Minimum Gas Supply Pressure | 11.0 in. W.C. (2.739 kPa) |
| Manifold Pressure | 10.0 in. W.C. (2.490 kPa) |
| Installation | Freestanding |
| Width | 27 in. |
| Height | 27 in. |
| Depth | 16 in. |
Included
- Medium Steel Stove
- 4-Piece Log Set
- Barrier Screen
- Slope Glaze Burner
Optional Accessories (Sold Separately)
- 45-Degree Elbow (Required)
- Black Porcelain Liner
- Automatic Blower
- Flex Gas Line
- Control Options
- Gas Conversion Kit
- Traditional Floor Pad
- Traditional Corner Floor Pad
- Stone Inlay Kit (Required for Floor Pad)
Warranty
- Combustion chamber: 10-year limited warranty
- Glass: Limited lifetime warranty
- Remote controls: 1-year limited warranty
- All other parts: 3-year limited warranty
Technical Documents & Manuals
Product FAQs
1. Does the Empire Spirit DVP30MS30FP require electricity to operate?
The stove uses a millivolt ignition system with a standing pilot and push-button piezo ignitor. Basic operation does not rely on household electricity, allowing many direct vent millivolt systems to continue providing heat during winter power outages.
2. What is included with the Empire Spirit Propane Gas Stove?
The package includes the medium steel stove, a 4-piece ceramic fiber log set, a barrier screen, and the Slope Glaze Burner. Additional accessories such as the blower, porcelain liner, and remote controls are available separately.
3. What heating capacity does the Empire Spirit DVP30MS30FP provide?
The stove has a maximum input rating of 26,500 BTU/hr and a minimum input rating of 21,000 BTU/hr. It is designed as a freestanding direct vent propane gas stove with millivolt control.
