The Empire Spirit 27 Inch Propane Gas Stove Direct Vent Medium Steel DVP30MS70FP is a freestanding direct vent heating stove designed for propane gas applications. The direct vent system draws combustion air from outside while exhausting combustion by-products outdoors, helping separate indoor room air from the combustion process. This design allows efficient room heating while supporting flexible installation options along an exterior wall or through the roof.
The intermittent pilot ignition system eliminates the need for a continuously burning pilot, providing greater energy savings compared to a standing pilot system. The stove features Empire's Slope Glaze Burner with an expanded ember bed, ceramic beads that create naturally swirling flames, and a hand-painted ceramic fiber log set for a realistic fire appearance. A barrier screen, medium steel stove body, and 4-piece log set are included.
Designed for rooms requiring dependable heat output, the stove delivers between 21,000 and 26,500 BTU/hr. It can operate with an optional remote control or thermostat and may serve as a primary heat source. Additional accessories, including blower options, liners, floor pads, and gas conversion kits, are available separately to customize the installation.
Features
- Direct vent system separates combustion air from indoor room air.
- Intermittent pilot ignition eliminates a continuously burning standing pilot.
- Empire Slope Glaze Burner with expanded ember bed produces realistic flame movement.
- Includes hand-painted ceramic fiber 4-piece log set and protective barrier screen.
- Compatible with optional remote controls or thermostat operation.
- Freestanding medium steel stove designed for propane gas installations.
Specifications
| Specification | Details |
|---|---|
| Brand | Empire |
| Series | Spirit |
| Model | DVP30MS |
| SKU | DVP30MS70FP |
| Fuel Type | Propane Gas |
| Vent Type | Direct Vent |
| Ignition | Intermittent Pilot |
| Installation | Freestanding |
| Maximum Input | 26,500 BTU/hr |
| Minimum Input | 21,000 BTU/hr |
| Vent Size | 4 x 6 5/8 in. |
| Gas Inlet | 3/8 in. |
| Orifice | 1.55 mm |
| Air Shutter Setting | Full Open |
| Maximum Supply Pressure | 13.0 in. W.C. (3.237 kPa) |
| Minimum Supply Pressure | 11.0 in. W.C. (2.739 kPa) |
| Manifold Pressure | 10.0 in. W.C. (2.490 kPa) |
| Width | 27 in. |
| Height | 27 in. |
| Depth | 16 in. |
Included
- Medium Steel Stove
- 4-Piece Log Set
- Barrier Screen
- Slope Glaze Burner
Required (Sold Separately)
- 45-Degree Elbow
- RCK20 Replacement Control Cover (required for RVKN or RVKP)
Optional Accessories
- Black Porcelain Liner
- Automatic Blower
- Flex Gas Line
- Control Options
- Gas Conversion Kit
- Traditional Floor Pad
- Traditional / Corner Floor Pad
- Stone Inlay Kit (required for floor pad)
Warranty
- Direct vent combustion chamber: 10-year limited warranty
- Glass: Limited lifetime warranty
- Remote controls: 1-year limited warranty
- All other parts: 3-year limited warranty
Technical Documents & Manuals
Product FAQs
Q1. What type of venting does the Empire Spirit DVP30MS70FP use?
The stove uses a direct vent system, which draws combustion air from outside and vents combustion by-products outdoors through a compatible venting system.
Q2. What ignition system is included with the Empire Spirit DVP30MS70FP?
This model uses an intermittent pilot ignition system. The pilot ignites only when needed, eliminating the continuously burning standing pilot found in millivolt systems.
Q3. What comes with the Empire Spirit DVP30MS70FP?
The stove includes a medium steel stove, Slope Glaze Burner, 4-piece hand-painted ceramic fiber log set, and a barrier screen. Certain installation components and accessories, including the required 45-degree elbow and RCK20 replacement control cover, are sold separately.
