Empire Hearth Spirit Direct Vent Steel Stove DVP20MS30FP is a propane gas heating appliance designed for freestanding installation with a sealed direct vent system. This Empire Spirit Propane Gas stove uses outside air for combustion while venting exhaust outdoors, helping separate combustion air from room air. The millivolt ignition system features a standing pilot with a push-button piezo ignitor and operates using the integrated on/off switch or compatible optional remote control systems.
The stove is equipped with Empire's Slope Glaze Burner system, an expanded ember bed, and a hand-painted four-piece ceramic fiber log set that creates a natural-looking flame appearance. With an input range of 13,500 to 19,500 BTU/hr, this Empire Spirit Gas stove can serve as a primary heat source where appropriate. The ceramic glass front allows thermal heat transfer while room air circulates around the sealed combustion chamber for effective warmth. Designed as a Direct Vent stove, this Steel stove combines a compact 22-inch design with realistic fire presentation and dependable propane performance. The unit includes a fireplace barrier screen and supports several optional accessories, including a blower, porcelain liner, thermostat or remote controls, floor pads, and a gas conversion kit.
Features
- Direct vent system separates combustion air from indoor room air.
- Millivolt ignition with standing pilot and push-button piezo ignitor.
- Operates using the built-in on/off switch and supports optional remote or thermostat controls.
- Slope Glaze Burner with expanded ember bed produces realistic flame movement.
- Includes a hand-painted four-piece ceramic fiber log set and fireplace barrier screen.
- Freestanding 22-inch steel stove with heating capacity up to 19,500 BTU/hr.
Specifications
| Specification | Details |
|---|---|
| Brand | Empire Hearth |
| Series | Spirit |
| Model | DVP20MS |
| SKU | DVP20MS30FP |
| Product Type | Direct Vent Steel Stove |
| Fuel Type | Propane Gas |
| Installation | Freestanding |
| Vent Type | Direct Vent |
| Vent Size | 4 x 6 5/8 |
| Ignition | Millivolt Control |
| Maximum Input | 19,500 BTU/hr |
| Minimum Input | 13,500 BTU/hr |
| Width | 22 in |
| Height | 23 in |
| Depth | 16 in |
| Gas Inlet | 3/8 in |
| Orifice | 55 |
| Air Shutter Setting | Full Open |
| Maximum Supply Pressure | 13.0 in. W.C. (3.237 kPa) |
| Minimum Supply Pressure | 11.0 in. W.C. (2.739 kPa) |
| Manifold Pressure | 10.0 in. W.C. (2.490 kPa) |
Included
- Small Steel Stove
- Four-Piece Log Set
- Fireplace Barrier Screen
- Slope Glaze Burner
Optional Accessories (Sold Separately)
- 45 Degree Elbow (Required)
- Black Porcelain Liner
- Automatic Blower
- Flex Gas Line
- Control Options
- Gas Conversion Kit
- Traditional Floor Pad
- Traditional Corner Floor Pad
- Stone Inlay Kit
Warranty
- Combustion chamber: 10-year limited warranty
- Glass: Limited lifetime warranty
- Remote controls: 1-year limited warranty
- All other parts: 3-year limited warranty
Technical Documents & Manuals
Product FAQs
Q1. What type of venting does the Empire Spirit DVP20MS30FP use?
The Empire Spirit DVP20MS30FP uses a direct vent system that draws combustion air from outdoors while venting combustion by-products outside through a sealed venting system.
Q2. What is the heating capacity of this Empire Spirit propane gas stove?
This model delivers an input range of 13,500 BTU/hr to 19,500 BTU/hr, depending on operating conditions and settings.
Q3. What is included with the Empire Spirit DVP20MS30FP?
The stove includes the small steel stove, a four-piece hand-painted ceramic fiber log set, a fireplace barrier screen, and Empire's Slope Glaze Burner system. Optional accessories such as a blower, remote controls, porcelain liner, floor pads, and gas conversion kit are available separately.
