The Empire Spirit 22" Natural Gas Stove is a compact Direct Vent stove designed to provide dependable supplemental or primary heat while keeping combustion air separate from indoor living spaces. This Empire Spirit Gas stove features a porcelain black cast iron exterior and a millivolt ignition system with an integrated on/off switch, allowing operation even during many winter power outages because it does not rely on household electricity for basic function. The direct vent design uses outside air for combustion and vents exhaust outdoors, supporting efficient and sealed operation.
Inside, Empire's Slope Glaze Burner system combines ceramic beads, glowing embers, and a hand-painted four-piece ceramic fiber log set to create naturally moving flames with the appearance of a traditional wood fire. The expanded ember bed enhances the visual presentation while maintaining the performance of a gas heating appliance. This Empire Spirit Natural Gas stove is designed for freestanding installation and supports optional remote control or thermostat operation. With an input range of 13,500 to 19,500 BTU/hr, it delivers steady heat output in a compact footprint while maintaining the classic appearance of a cast iron stove.
Features
- Direct vent system draws combustion air from outdoors and vents exhaust outside.
- Millivolt ignition with concealed on/off switch for dependable operation.
- Empire Slope Glaze Burner system with expanded ember bed for realistic flame appearance.
- Hand-painted four-piece ceramic fiber log set with glowing embers.
- Porcelain black cast iron construction for a classic freestanding stove design.
- Compatible with optional remote control or thermostat operation.
Specifications
| Specification | Details |
|---|---|
| Brand | Empire Hearth |
| Product Series | Spirit |
| Model | DVP20CC |
| SKU | DVP20CC30BN |
| Fuel Type | Natural Gas |
| Vent Type | Direct Vent |
| Installation | Freestanding |
| Finish | Porcelain Black |
| Material | Cast Iron |
| Ignition Type | Millivolt |
| Maximum Input | 19,500 BTU/hr |
| Minimum Input | 13,500 BTU/hr |
| Vent Size | 4" x 6 5/8" |
| Gas Inlet | 3/8" |
| Orifice | 2.15 mm |
| Air Shutter Setting | 1/8" |
| Maximum Gas Supply Pressure | 10.5" W.C. (2.614 kPa) |
| Minimum Gas Supply Pressure | 4.5" W.C. (1.121 kPa) |
| Manifold Pressure | 3.5" W.C. (0.872 kPa) |
| Width | 21" |
| Height | 24" |
| Depth | 16" |
What's Included
- Small Cast Iron Stove
- 4-Piece Log Set
- Fireplace Barrier Screen
- Slope Glaze Burner
Optional Accessories (Sold Separately)
- 45-Degree Elbow (Required)
- Black Porcelain Liner
- Automatic Blower
- Flex Gas Line
- Control Options
- Gas Conversion Kit
- Cast Iron Stove Shelf Kit
- Traditional Floor Pad
- Traditional / Corner Floor Pad
- Stone Inlay Kit (Required for Floor Pad)
Warranty
- Direct vent combustion chamber: 10-Year Limited Warranty
- Glass: Limited Lifetime Warranty
- Remote controls: 1-Year Limited Warranty
- All other parts: 3-Year Limited Warranty
Technical Documents & Manuals
Product FAQs
Q1. What type of venting does the Empire Spirit DVP20CC30BN use?
The Empire Spirit DVP20CC30BN uses a direct vent system, which draws combustion air from outside the home and vents combustion by-products outdoors through a dedicated vent system.
Q2. Can this stove operate during a power outage?
Yes. This model uses a millivolt ignition system with a standing pilot and on/off switch. The product information states that most millivolt systems can provide heat during a winter power outage.
Q3. What is included with the Empire Spirit DVP20CC30BN?
The stove includes a small cast iron stove, a four-piece ceramic fiber log set, a fireplace barrier screen, and the Slope Glaze Burner system. Additional accessories such as a blower, remote controls, and floor pads are available separately.
